| AC Output |
Nominal AC Output Power |
10,000 W (10 kW) |
High output for large loads. |
|
Max Continuous AC Current |
41.6A @ 240VAC |
|
|
Max UPS (Backup) Output |
10,000 W |
Full capacity is available during an outage. |
|
Surge Power (Peak) |
20kW for 500ms |
Excellent surge capability. |
|
Output Waveform |
Pure Sine Wave |
|
|
Switching Time (UPS) |
< 20ms |
Fast switchover for critical loads. |
| Solar Input (PV) |
Max. PV Array Power (Total) |
$16,000W |
Allows for 60% oversizing on the PV side. |
|
Number of MPPT Inputs |
3 Independent MPPTs |
2 / 1 / 1 string configuration. |
|
Max. DC Input Power per MPPT |
12,000W / 7,000 W / 7,000W |
The first MPPT can handle a larger array. |
|
MPPT Voltage Range |
210V ~ 500V |
Optimal operating voltage range. |
|
Max. PV Open Circuit Voltage |
600V DC |
Absolute max voltage limit. |
| Battery |
Compatible Battery Type |
Lead-Acid / Lithium-ion |
|
|
Nominal Battery Voltage |
48V DC |
|
|
Battery Voltage Range |
40V DC~60V DC |
|
|
Max. Charge/Discharge Current |
210A |
Very high current capability for fast charging/discharging a large battery bank. |
|
Max. Charge/Discharge Power |
10,000W |
Matches the nominal output power. |
| General |
Max. Efficiency |
_>97.5% |
|
|
MPPT Efficiency |
99.9% |
|
|
Ingress Protection (IP Rating) |
IP65 |
Suitable for outdoor installation. |
|
Communication Interface |
CAN, RS485, Wi-Fi |
CAN for smart battery BMS (e.g., Hubble, Pylontech). |
|
Parallel Function |
Up to 10 Units |
Scalable for up to a 100 kW system. |
|
Dimensions (W x H x D) |
approx 650mm x 440mm x 220mm |
Dimensions vary slightly, but it is a large unit. |
|
Weight |
approx 40kg |
|
|
Key Feature |
Separate Generator Port |
Allows for dedicated connection and control of a generator. |
